Technical Information
33
Master Chef Ovens
5.3 Runners – Removal
Figure 5-2: Removing The Runners From The Oven Cavity.
1. Turn the two thumbscrews, (Figure 5-2) counterclockwise and
remove.
2. Pull the runners away from the oven wall to remove.
(Figure 5-2)
5.4 Halogen Light Bulb - Replacement
1. Remove the runners.
2. Spread a dishtowel on the oven floor to protect the enamel, in
case the light cover falls.
3. Insert the supplied lid opener between the light cover and the
metal frame of the light along the edge closest to the oven door.
Figure5-3: Prying The Light Cover Off
