Technical Information
32
Master Chef Ovens
5.2 Front Door – Removal
Important
DO NOT hold the door by the handle. When handling the door it should
be gripped firmly on the sides (glass and frame).
1. Open the door fully.
2. Flip up the locking clamps on each door hinge.
3. Slowly shut the door until the protruding clamps stop the
movement. Pull the door upward to remove.
Figure 5-1: Door Hinge – Locking Tabs
