Technical Information
50
Master Chef Ovens
5.24 Convection Fan – Removal (1M2/2, 2M2/2)
1. Refer to Figure 5-17.
2. Remove the Front Doors (Section 5.2).
3. Remove the oven (Section 5.5).
4. Remove the Back Panel (Section 5.9 and / or 5.10)
5. Remove the Oven Cavity Back Panel (Section 5.21)
6. Loosen the Fan Blade Nut (Item 2).
Note
The Fan Blade Nut is reverse thread.
7. Remove Fan Blade, Washer (Item 3) and Bushing (Item 4).
8. Refer to Figure 5-18. Remove the three Retaining Screws.
9. Unplug the electrical connection. Remove the component.
Figure 5-18: Convection Fan Motor and Retaining Screws
