Technical Information
45
Master Chef Ovens
Figure 5-13 Door Latch Assembly
6. Refer to Figure 5-13. Remove the two screws that secure the Latch
Assembly to the Cavity Assembly.
7. Slightly lift the Upper Housing near the front to access the Latch
Assembly, as shown in Figure 5-14.
Service Tip - Upper & Lower Door Close Switch Removal
To simplify access to the Door Switch Retaining Tabs, the Right Side
Panel can be removed permitting direct access to the underside of the
locking tabs.
