Built-under ("U")
,
To ensure stability, built-under
dishwashers must be installed under
a continuous length of worktop
which is secured to neighbouring
units.
–
Building-under:
Built-under machines should be instal
-
led under a continuous worktop or sink
drainer.
The recess must be at least 60 cm
wide, 60 cm deep and 82 cm high.
Built-under dishwashers are supplied
without a lid or rear panel.
Depending on the requirements for
building under, the following kits can be
ordered from Miele:
Cover plate (protects the worktop)
The underside of the worktop is protec-
ted against water damage by a stain-
less steel plate.
Decor frame fitting kit
The machine front can be fitted with a
decor panel to match kitchen units.
The decor frame is supplied with fitting
instructions.
Aligning and securing a "U" dishwas
-
her
To ensure stability, the dishwasher
must be fixed securely to the worktop.
Two securing pieces are supplied with
the dishwasher for this purpose.
^ Fit the securing pieces into the slots
on both the left and right hand sides.
^ Push the dishwasher right back into
its recess (making sure it is correctly
aligned).
^
Open the dishwasher door.
The holes in the securing pieces
must line up with the long holes in
the worktop cover plate. If this is not
the case, adjust the position of the
dishwasher in the niche (ensure that
the dishwasher is the same distance
from the neighbouring kitchen units
on the right and left hand sides and
line the dishwasher door front up
with neighbouring door fronts).
Installation
64
