Cleaning and care
37
Cleaning the water inlet filters
The washing machine has filters to pro-
tect the water inlet valves. You should
inspect the filters approximately every
6months. Perform this check more of-
ten if there are frequent interruptions to
the external water supply.
Cleaning the filter in the inlet hose
 First turn off the stopcock.
 Unscrew the inlet hose from the stop-
cock.
 Remove the rubber seal 1 from the
recess.
 Using pointed pliers, take hold of the
plastic filter bar 2 and remove it.
 Clean the plastic filter.
 Reassemble in reverse order.
Make sure there is no water leaking
from the screw thread.
Tighten the screw thread.
Cleaning the filter in the inlet valve
 Using pliers, carefully loosen the
ribbed plastic nut on the inlet valve
and unscrew.
 Use pointed pliers to withdraw the
plastic filter by the bar.
 Clean the filter.
 Reassemble in reverse order.
The filters are used to protect the
water inlet valve.
The filters must be put back in place
after cleaning.

Miele PWM 300 SmartBiz Specifications

General

Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	No
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	0.76 kWh
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min
Package depth	690 mm
Package width	660 mm
Package height	944 mm
Package weight	95000 g

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
Weight	91000 g
Door diameter	300 mm
Depth with door open	1054 mm
