Miele PWM 300 SmartBiz User Manual

Installation
*INSTALLATION*
54
 Use a level to check that the washing
machine is standing level.
 Hold foot 1 securely with a pipe
wrench. Turn counter nut 2 again us-
ing the spanner supplied until it sits
firmly up against the housing.
 Risk of damage due to incor-
rectly aligned washing machine.
There is a danger of the washing ma-
chine moving about if the feet are not
secured.
Turn all 4 counter nuts for the feet
until they sit firmly up against the
housing. Please also check this for
the feet which did not need adjust-
ment.
Securing the washing machine to the
plinth
 Secure the front feet of the washing
machine using the clamps supplied.
 Follow the fitting instructions sup-
plied.
Installing under a continuous work-
top
 Risk of electric shock due to ex-
posed cables
There is a risk of coming into contact
with live parts while the lid is re-
moved.
Do not remove the washing machine
lid.
This washing machine (with lid intact)
can be pushed under a countertop if
there is space to do so.

Miele PWM 300 SmartBiz Specifications

General

Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	No
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	0.76 kWh
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min
Package depth	690 mm
Package width	660 mm
Package height	944 mm
Package weight	95000 g

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
Weight	91000 g
Door diameter	300 mm
Depth with door open	1054 mm
