Miele PWM 300 SmartBiz User Manual

Programmable functions
65
End of programme tone
The tone that sounds at the end of a
programme can be changed or
switched off.
Options
 = Off (factory default setting)
 = Normal
 = Loud
Sensor control tone
The tone that sounds when a sensor
control is pressed can be changed or
switched off.
Options
 = Off
 = Normal (factory default set-
ting)
 = Loud
PIN code
The PIN code prevents the washing
machine being used without your
knowledge.
If you activate the PIN code, you have
to enter a PIN code after switching the
washing machine on. Otherwise it can-
not be operated.
Options
 = Off (factory default setting)
 = On
If the option has been selected, you
will have to enter the PIN code before
you can operate the washing machine.
Using the washing machine with a
PIN code
The code is 125 and cannot be altered.
 Switch on the washing machine.
  appears on the time display and
theandsensor controls light up.
 Touch the sensor control twice.
 appears on the time display.
 Confirm the number with the Start/
Stopsensor control.
The first number has been saved and
you can now enter the second number
using theandsensor controls.
 Enter the second and third numbers
and confirm the numbers with the
Start/Stopsensor control.
The lock is released and a wash pro-
gramme can now be selected and star-
ted.

Miele PWM 300 SmartBiz Specifications

General

Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	No
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	0.76 kWh
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min
Package depth	690 mm
Package width	660 mm
Package height	944 mm
Package weight	95000 g

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
Weight	91000 g
Door diameter	300 mm
Depth with door open	1054 mm
