Miele PWM 300 SmartBiz User Manual

Technical data
59
Height 850mm
Width 596mm
Width (machines with a stainless steel lid) 605mm
Depth 636mm
Depth with door open 1054mm
Weight Approx. 90kg
Maximum floor load in operation 3000newtons
Capacity 7.0kg dry laundry
Supply voltage See data plate on back of appli-
ance
Rated load See data plate on back of appli-
ance
Fuse rating See data plate on back of appli-
ance
A-rated sound emissions L
pA
in accordance
with ENISO11204/11203
<70dB re 20µPa
Minimum water flow pressure 100kPa (1bar)
Maximum water flow pressure 1,000kPa (10bar)
Inlet hose length 1.55m
Drain hose length 1.50m
Connection cable length 2.00m
Product safety standard EN 50571, EN 60335
Test certifications awarded See data plate

Miele PWM 300 SmartBiz Specifications

General

Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	No
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	0.76 kWh
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min
Package depth	690 mm
Package width	660 mm
Package height	944 mm
Package weight	95000 g

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
Weight	91000 g
Door diameter	300 mm
Depth with door open	1054 mm
