Miele WTD 160 User Manual

Technical data
80
Height 850mm
Width 596mm
Depth 637mm
Depth with door open 1055mm
Weight Approx. 98kg
Capacity, washing
Capacity, drying
8.0kg dry laundry
5.0kg dry laundry
Supply voltage See data plate
Rated load See data plate
Fuse rating See data plate
Consumption data See “Consumption data”
Minimum water flow pressure 100kPa (1bar)
Maximum water flow pressure 1000kPa (10bar)
Water inlet hose length 1.55m
Drain hose length 1.50m
Connection cable length 2.00m
Maximum delivery head 1.00m
Maximum drainage length 5.00m
LEDs Class 1
Test certifications awarded See data plate
Power rating in off mode 0.30
Networked standby 0.70
Frequency band of the WiFi module 2.4000GHz – 2.4835GHz
Maximum transmitting power of the
WiFi module
<100mW

Miele WTD 160 Specifications

General

Brand	Miele
Model	WTD 160
Category	Washer/Dryer
Language	English
