Milton Roy mRoy XT User Manual

37
6.4 PARTS LIST FOR XT MOTOR / MOUNT
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
9, 10, 11 320 Gear, Worm, 9.5:1, 185 SPM@ 1725
RPM
2520086201 1
320 Gear, Worm, 15: 1, 117 SPM@ 1725
RPM
2520019200 1
320 Gear, Worm, 24:1, 73 SPM@ 1725 RPM 2520090201 1
320 Gear, Worm, 48:1, 37 SPM@ 1725 RPM 2520052001 1
320 Gear, Worm, 77:1, 23 SPM@ 1725 RPM 2520125001 1
330 Shaft, Worm Gear, Steel 20341 1
340 O-Ring, 2-028, Nitrile, 70 Duro 40310 1
350 Plug, 1/4in. NPT Sq Head, 18.8 SS 4020009116 1
360 Nut, Hex, 5/16 - 18NC 18.8 SS 4050065013 4 FS
370 Washer, Spring Lock, 5/16in. 4040040028 4 FS
375 Nut, Hex, M8, Class 8, SS 4350000042 2 SS
380 Screw, Hex Head, 3/8in.- 16in. X 1in.
GR5 ULTRA
4050018119 4 FR, F4
380 Screw, Hex Head, 5/16in.- 18in. X 1-1/4
in. GR5
4050017139 4 FS
380 Screw, Hex Head, M10 X 25MM Steel 4350001732 8 MD
385 Washer, Spring Lock, 5/16in. 4040040028 2 SS
390 Plug, Pipe 1/2in. NPT 4020009137 1 FR, F4, MD
390 Plug, 1/4in., 18-8SS 4020009116 FS
395 Adapter, Flange, API 20864 1 FR, F4, FS,
MD
400 Screw, Hex Head, 3/8in.- 16in. X 1-1/2in.
18.8SS
4050018143 2 SR, FS, MD
400 Screw, Socket Head, 8MM X 1.25 THD 40322 2 SS
400 Screw, Hex Head, 3/8in.- 16in. X 1-1/2in.
18.8SS
4050018143 4 FR, F4
410 Shaft, Worm 2520157006 1 SR
410 Shaft, Worm 2520167006 1 SS
- Items Not Shown
Model:
Description: ReferenceCode:
Close Coupled Flange, NEMA 56C ------------- SR
Close Coupled Flange, IEC Frame 71, B5 --- SS
API Flange Mount, NEMA 56C ------------------ FR
Description:
ReferenceCode:
API Flange Mount, NEMA 143TC -------------- F4
API Flange Mount, IEC Frame 71, B5 --------- FS
API Flange Mount, IEC Frame 80, B5 --------- MD
