6.6 PARTS LIST FOR MROY XW DRIVE / LIQUID END
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
13, 14, 15 10 Housing 21480 1
20 Race, Cup, Tapered Roller 4090066020 1
30 Poppet, Relief, Steel 20381 1
40 Spring 2800046541 1
50 Screw, Adjusting, Brass 2560037051 1
60 Plug, 1/4in. NPT, 18-8 SS 4020009116 1
90 Plunger 20372 1
100 Rod, Connecting 2140013162 1
110 Pin, Wrist, Steel 2110037006 1
120 Gear, Worm, 9.5:1 2520088201 1
120 Gear, Worm, 12.5:1 2520081201 1
120 Gear, Worm, 19:1 2520092201 1
120 Gear, Worm, 25:1 2520082201 1
120 Gear, Worm, 38:1 2520094201 1
130 Shaft, Worm Gear 20382 1
140 Plunger, 9/16in. 20342 1
180 Screw, Soc Set, #6-32NC X 1/4 4050039035 2
190 Decal, Capacity 2530026062 1
200 Ring, Calibration, Aluminum 2530025062 1
210 Knob, Control, 316SS 2550046016 1
215 O-Ring, 2-031, Nitrile, 90 Duro 41064 1
216 O-Ring, 2-015, Nitrile, 90 Duro 40334 1
217 Ring, Back Up, 8-015, Nitrile 40335 1
220 Clip E Ring External 4049983151 1
225 Cap, Seal 21497 1
230 Rod, Control, Steel 20373 1
242 Screw, HEX HD, 3/8-16 X 2 ULTRA GR5 4050018169 3
244 Washer, Spring Lock, 3/8 18.8SS 4040041022 3
- Items Not Shown
Model:
Description: ReferenceCode:
API Flange Mount, NEMA 56C ------------------ FR
API Flange Mount, NEMA 143145C --------------F4
Description:
ReferenceCode:
API Flange Mount, IEC Frame 80, B5 --------- F8
API Flange Mount, IEC Frame 90, B5 --------- F9
