- 14 -
The motor alarm and the over current have
occurred
An error has occurred because too much load was applied to the motor to feed the media (A motor)
and the motor to move the pen (cutter blade) right and left (B motor).
(1) If Error 40 A motor alarm and Error 42 A over current are displayed, check the following
items:
(2) If Error 41 B motor alarm and Error 43 B over current are displayed, check the following
items:
Plotting does not match the cut line
The roll sheet has expanded and shrunk
The main cause is that the sheet has expanded and shrunk.
Roll sheet may expand or shrink not a little due to the environment change by changing its status of
being taken-up to sagging. Because of this, the position relationship at the end of cutting may be dif-
ferent from that at the start, or, the paper may skew and slant.
By acclimating the sheet to the using environment, you can prevent it from expanding/ shrinking.
Be sure to perform “pre-feed” before cutting/ plotting, acclimate the sheet to the using environment.
For the pre-feed, refer to the Operation manual chapter 3 “Setting the PRE FEED”.
The roll sheet is misaligned
Because the roll sheet is misaligned, plotting may not match the cut line.
By referring to P.11 "When you cut off the sheet after cutting", adjust the sheet misalignment.
Is the specified sheet
used?
Check that the weight, the thickness and the width are within the specifica-
tion. If you use a roll sheet other than specified, stable feeding cannot be
performed.
For the roll sheet specification, refer to P.10 "Settable paper".
Isn’t a heavy roll
sheet used?
When you use a heavy roll sheet, set “Sheet setting” of the setting function
to “HEAVY”.
For the setting method, refer to the Operation manual chapter 3 “Setting
the SHEET TYPE”.
Has paper jam
occurred?
By referring to P.15 "Paper jam has occurred", remove the jammed paper.
Has paper jam
occurred?
By referring to P.15 "Paper jam has occurred", remove the jammed paper.
To Next Page
