- 16 -
What is HALF CUT?
Half cut set in APC-130 is explained here.
The cut line of APC-130 is a dotted line with the part to be cut and the part to be left (not to be cut)
one after the other to make a pattern easier.
In APC-130, also cut the surface of the part to be left (HALF LENGTH) with light pressure so that the
pattern can be removed beautifully after cutting.
Cutting
direction
Sheet
Set the length to be
left (not to be cut)
(HALF LENGTH)
Set the length
to be cut
(CUT LENGTH)
Cutting pressure of the part
to be left (not to be cut)
(HALF PRESS)
Cutting pressure of
the part to be cut
(PRESS)
Depending on the setting value of HALF CUT, the pattern tends to come off during
cutting. Be careful about it.
• The pressure of the part to be left (HALF PRESS) is too high.
• The part to be left (HALF LENGTH) is too short.
• The part to be cut (CUT LENGTH) is too long.
For the setting method of half cut and the reference for the cutting condition, refer to the
Operation manual.
• Setting method of half cut : Operation manual chapter 2 “Set the Tool Condition”
• Reference for cutting condition : “Reference for cutting condition” of the Operation
manual chapter 2 “Set the Tool Condition”
To Next Page
