A - 11
• The equipment startup time in the fast startup mode is less than 2s.
A.7.2 CPR Compression Specifications
Compressions from CPR Sensor
Compressions from Electrode Pads
A.7.3 Pacer Specifications
• When pacing rate is changed from 30ppm to 210ppm, the response time to pacing (HR rising from
30bpm to 210bpm) is less than 20s.
A.8 Monitor Specifications
A.8.1 ECG Specifications (from ECG Accessories)
Compression rate Measurement range: 40 to 160 cpm
Accuracy: ±2 cpm
Compression rate Measurement range: 60 to 200 cpm
Accuracy: ±3 cpm
Standards Meet standards of IEC 60601-2-4
Pacer mode Demand, fixed
Output waveform Monophasic square wave pulse
pulse width 20 ms or 40 ms
Accuracy: ±5%
Pacing rate 30ppm to 210ppm
Accuracy: ±1.5%
Resolution: 5 ppm
Pacing output 0mA to 200mA,
Accuracy: ±5% or ±5mA, whichever is greater
Resolution: 1mA, 2mA or 5mA
Refractory period 200 to 300 ms (depending on pacing rate)
4:1 pacing Pacing pulse frequency reduced by factor of 4 when this function is
activated.
Standards Meet standards of IEC 60601-2-27 and IEC 60601-2-25
Patient connection 3-lead ECG cable, 5-lead ECG cable or 12-lead ECG cable
ECG inputs 3-lead ECG:
5-lead ECG:
12-lead ECG:
I, II, III
I, II, III, aVR, aVL, aVF, V
I, II, III, aVR, aVL, aVF, V1 to V6
ECG standard AHA, IEC
Display sensitivity 1.25 mm/mV (×0.125), 2.5 mm/mV (×0.25), 5 mm/mV (×0.5), 10 mm/mV (×1),
20 mm/mV (×2), 40mm/mV (×4), Auto, less than ± 5% error
