P/N: 046-003757-00 Rev A
Quick Reference Guide
12
Note: Cardiac index is calculated if height/weight have been entered in the
Patient Setup menu
e. Wait 1 minute between injections to allow baseline stabilization
f. Perform additional Cardiac Output measurements as needed
g. Select measurement to include/exclude in the Cardiac Output average
(A in the box indicates cardiac output measurement is selected)
h. Select
a. Stop to stop the current measurement
b. Cancel to delete most recent cardiac output measurement as needed
c. Record to print the most recent cardiac output measurement and
numeric data
i. Select Main Menu
(quick key) or to return to the main display
or select Calc>> to access the Hemodynamic Calculations menu
Note: Blood temperature alarms are inactive when a cardiac output
measurement is initiated.
Initiate Pulmonary Artery Wedge Pressure (PAWP)
Pulmonary Artery Wedge Pressure (PAWP) is a pressure measurement derived
from a PA catheter when the PA distal balloon is inflated and the catheter
advances and occludes a distal pulmonary artery. PAWP pressure is a reflection
of the pressure in the left ventricle at end-diastole.
To initiate a PAWP measurement on the DPM 6 or DPM 7 bedside monitor:
a. Select PAWP menu by selecting PA invasive blood pressure tile or from
Parameters menu (
or Main Menu quick keys)
Or
a. Select PAWP
(quick key)
b. Select Setup to adjust PA sweep speed, PA scale, or reference waveforms
(as needed)
c. Inflate balloon and watch PA waveform for wedge waveform
d. Select Freeze to freeze the waveform once a satisfactory wedge
waveform is detected
To Next Page
