Quick Reference Guide
17
d. A  in the waveform box indicates waveform is selected
e. Select Confirm to return to Full Disclosure tab
f. Select Main Menu
(quick key) or to return to the main display
To record waveforms stored on a patient:
a. Select Review menu
(quick key) or from Main Menu (quick
key)
b. Select Full Disclosure tab
c. Select Record to record the first three saved waveforms
Panorama® Central Station Interface: Full disclosure storage and printing
on the DPM 6 or DPM 7 bedside monitor and Panorama® Central Station are
independent.
VOLUMES
The alarm volume, key volume, and QRS volume can be adjusted on the DPM 6
or DPM 7 bedside monitors.
To adjust the alarm volume on the DPM 6 or DPM 7 bedside monitor:
a. Select Volume
(quick key) or select Others in the Alarm Setup
(quick key)
b. Select Alm Vol
c. Select volume ranging from X*-10 (0=Off 10=Max)
d. Select Main Menu
(quick key) or to return to the main display
*Note: The minimum volume range is predetermined during installation.
Key Volume
To adjust the key volume on the DPM 6 or DPM 7 bedside monitor:
a. Select Volume
(quick key)
b. Select Key Vol
c. Select volume ranging from 0-10 (0=Off 10=Max)
d. Select Main Menu
(quick key) or to return to the main display
