T1 Service Manual 3-3
Battery charger, T1 Docking Station, and T1 Handle
Item Operating conditions Storage conditions
Temperature (°C) 0 to 40 -20 to 60
Relative humidity (noncondensing) 15% to 95% 10% to 95%
Barometric (kPa) 57.0 to 107.4 16.0 to 107.4
NOTE
The environmental requirements of unspecified parameters are the same as those of the main unit.
3.2.2 Electrical Requirements
T1 can be connected to AC power source through the T1 Docking Station or connected to external power through a DC
adapter. Only power sockets with protective grounding can be used. Make sure that:
1. All cables and connectors are not damaged, and pins are not loose. Otherwise, remove it from use.
2. The insulation of patient cables and leadwires is not damaged, and connectors are not loose.
The electrical specification of the DC adapter is as follows:
Line voltage
100 to 240 VAC (±10%)
Current
0.6 to 0.4 A
Frequency
50/60 Hz (±3 Hz)
The electrical specification of the T1 Docking Station is as follows:
Line voltage
100 to 240 VAC (±10%)
Current
0.65 to 0.35 A
Frequency
50/60 Hz (±3 Hz)
Preparation for Power On:
1. Before you begin taking measurements, check the patient monitor for any mechanical damage, and make sure that all
external cables, plug-ins and accessories are properly connected.
2. If you run T1 on external DC power, connect T1 with the DC adapter. If you run T1 on battery power, ensure that the
battery is sufficiently charged. If you run T1 on T1 Docking Station, connect the power cord of the Docking Station to AC
power and check if the power indicator on the Docking Station lights up.
3. Press the power on/off switch on the monitor’s front.
