6-4 T1 Service Manual
6.6.5 T1 Docking Station and T1 Handle Failure
Symptoms Possible Cause Correction Action
Failed to identify parameter
modules
T1 handle NIOS board defective Replace the T1 handle NIOS board
T1 handle converter board
defective
Check the connection between the T1 handle
converter board and the T1 handle NIOS board. If
properly connected, replace the T1 handle converter
board.
Main board defective Replace the main board
No video output Dock interface board defective Replace the Dock interface board.
Dock converter board defective Replace the Dock converter board.
Main board defective Replace the main board of the Docking Station
Fail to connect Passport 12m or
17m patient monitor
Dock interface board defective Replace the Dock interface board.
No power output from the T1
Docking Station
Dock power board defective Replace the Dock power board.
Unable to connect the preset
CMS or correctly display bed
number or department
External display incompatible Replace the screen.
The external display turns black
when T1 is installed to the T1
Docking Station
Error caused by hot plug Reinstall T1.
Incorrect connection sequence Connect the external display and T1 Docking Station
first and then install or start T1.
The touchscreen of the external
display does not work
USB connection error Reinstall or restart T1.
6.6.6 System Running Failure
Symptoms Possible Cause Correction Action
The equipment does not respond System program failure Reinstall the system software,
Main board is defective Replace the main board.
No connection when inserted into Passport
12m or 17m patient monitor
Infrared communication board
defective
Replace the infrared communication board
Connected but no data transmitted with
Passport 12m or 17m patient monitor
Main board defective Replace the main board.
System time is being reset Backup battery failure Replace the backup battery
The charging circuit for the
backup battery is faulty
Replace the infrared communication board.
Main board is defective Replace the main board.
