Mindray V21 Quick Reference Guide

Quick Reference Guide
V
V
V
P/N: 0002-08-50038-00 Rev A
13
ECG
Adjust ECG Lead
The V12 or V21 bedside monitor allows the clinician to adjust the leads being
viewed on the main screen.
To adjust an ECG Lead on the V12 or V21 bedside monitor:
a. Select ECG waveform to enter ECG Setup tab
b. Select ECG Leads
c. Scroll and select lead from drop down menu
d. Select Accept to save settings and return to the main screen
Panorama® Central Station Interface: Adjusting ECG leads on the V12 or V21
bedside monitor, Panorama® Central Station, WorkStation, and ViewStation are
independent.
Enable Pacemaker Detection
The V12 or V21 bedside monitor allows the clinician to enable pacemaker
enhancement.
To enable the pacemaker enhancement on the V12 or V21 bedside monitor:
a. Select ECG waveform to enter ECG Setup tab
Or
a. Select Parameters (Setup tab) and select ECG to enter ECG Setup tab
b. Select Pacer tab
c. Select Pacer Enhancement and select On
d. Select Accept to save settings and select Done (as needed) to return to
the main screen
Panorama® Central Station Interface: Pacemaker enhancement on the V12 or
V21 bedside monitor, Panorama Central Station, WorkStation, and ViewStation
are independent.
