a. Select History in the Navigation Area
b. Select Full Disclosure tab
c. Scroll and highlight waveform
d. Select View and Detail to expand waveform
e. Select Print to print to the configured location
f. Select Done to return to the main screen
Panorama® Central Station Interface: Full disclosure storage and printing
on the V12 or V21 bedside monitor and Panorama Central Station are
independent.
VOLUMES
The alarm volume and QRS volume can be adjusted on the V12 or V21 bedside
monitors.
To adjust the alarm volume on the V12 or V21 bedside monitor:
a. Select Setup tab from Navigation area
b. Select Audio Levels
c. Select volume ranging from X*10 (X=minimum, 10=max)
using arrows on Alarm Volume
d. Select Accept to return to the main screen
*Note: The minimum volume range is predetermined during installation (Version 2.5 or greater)
BEAT TONE
To adjust the beat tone (QRS tone) volume on the V12 or V21 bedside monitor:
a. Select Setup tab from Navigation area
b. Select Audio Levels
c. Select volume ranging from 010 (0=Off, 10=Max)
using arrows on Beep Volume
d. Select Accept to return to the main screen
Note: The QRS tone is derived from the HR source (ECG, SPO
2
, or IBP). When
monitoring SpO
2
, there is a variable pitch tone which changes as the patient’s
saturation level changes. The pitch of the tone rises as the saturation level
increases and falls as the saturation level decreases.
