Mindray V21 Quick Reference Guide

Quick Reference Guide
V
V
V
P/N: 0002-08-50038-00 Rev A
17
Note: If viewing on V12 monitor selecting View All ECG a second time will
display the next 6 leads and selecting View All ECG a third time will remove
viewing of 12 Lead ECG
Print 12 Lead ECG
To print a 12 Lead ECG Interpretive Report on V12 or V21 bedside monitor:
a. Select Print tab in Navigation Area
b. Select Print 12 Lead to print to the configured location
Or
a. Select Procedures tab in Navigation Area
b. Select 12 Lead
c. Select Print 12 Lead to print to the configured location
d. Select Accept to return to the main screen
NIBP
Initiate a Non-Invasive Blood Pressure Measurement (NIBP)
To initiate a NIBP measurement on a patient on the V12 or V21 bedside
monitor
a. Select on the VPS module
Or
a. Select Start NIBP* (Quick Function tab)
Or
a. Select NIBP tile to enter the Alarms tab and Select Start NIBP
b. Select Accept to return to the main screen
*Configurable
