Mindray V21 Quick Reference Guide

Quick Reference Guide
V
V
V
P/N: 0002-08-50038-00 Rev A
15
Initiate ECG Relearn
To initiate arrhythmia and ST learning manually on the V12 or V21 bedside
monitor:
a. Select ECG waveform to enter ECG Setup tab
Or
a. Select Parameters (Setup tab) and select ECG to enter ECG Setup tab
b. Select Relearn Both to update arrhythmia and ST templates
c. Select Accept to save settings and select Done (as needed) to return to
the main screen
Initiate QT Monitoring (Version 2.5 or greater)
a. Select ECG waveform to enter ECG Setup tab
Or
a. Select Parameters (Setup tab) and select ECG to enter ECG Setup tab
b. Select Advanced Arrhy Setup tab
c. Select QT Monitoring and select On
d. Select Accept to save settings and select Done (as needed) to return to
the main screen
Enable QTC Limit (Version 2.5 or greater)
a. Select ECG waveform to enter ECG Setup tab
Or
a. Select Parameters (Setup tab) and select ECG to enter ECG Setup tab
b. Select Advanced Arrhy Setup tab
c. Select QTC Limit
d. Select QTC High Range
e. Select Accept to save settings and return to the Advanced Arrhy Setup tab
f. Select Accept to save settings and select Done (as needed) to return to
the main screen
