Mitsubishi Electric A172SHCPUN User Manual

APPENDICES
APP
−
12
Appendix 1.3 A31TU-E Teaching Unit Cable
(1) A31TUCBL03M cable
(a) A31TUCBL03M cable appearance
EMG
EMGL
EMG1
EMG2
DED1
DED2
CPU module side A31TU-E side
(Solderless terminal 0.5-3)
(b) A31TUCBL03M cable connection details
Signal name
Pin No.
BA
3
BAL
16
CA
5
CAL 18
BB
2
BBL
15
CB
4
CBL
17
+5V
12
+5V
13
SG
7
+5V
24
+5V
25
SG
8
SG
20
AB
21
FG
1
EMG
22
EMGL
9
CPU module side
Connector
17JE-23250-02(D8A)
Manufactured b
y
DDK
BA
3
BAL
16
CA
5
CAL 18
BB
2
BBL
15
CB
4
CBL
17
+5V
12
+5V
13
SG
7
+5V
24
+5V
25
SG
8
SG
20
AB
21
FG
1
EMG1
22
EMG2
9
DED1
6
DED2
14
(Red)
(White)
A31TU-E side
Connector
DB-25SF-N
Manufactured b
y
JAE
Case
Signal name
Pin No.
(Red)
(White)
(Red)
(White)
