7.1 Option List
OPTIONS
198
7 OPTIONS
7.1 Option List
7.1.1 Stand-alone options
Name Type Application, Specifications, etc.
Applicable
Inverter
Parameter unit
(8 languages)
FR-PU04
Interactive parameter unit using LCD display (For use in Japanese,
English, German, French, Spanish, Italian, Swedish and Finnish)
Parameter unit
connection cable
FR-CB2
Cable for connection of the operation panel or parameter unit.
Common to
all models
Cooling fin protrusion
attachment
FR-A5CN
Used to place only the heat generating section of the inverter in
the back of the control box.
1.5K to 55K,
according to
capacity
totally enclosed
structure specification
attachment
FR-A5CV
By installing this option, the inverter meets the totally enclosed
structure specifications (IP40).
0.4K to 22K,
according to
capacity
Attachment for conduit
connection
FR-A5FN
Used to connect a conduit directly.
30K to 55K,
according to
capacity
FR-A200E series
installation interchange
attachment
FR-A5AT
Mounting plate used to make the mounting dimensions identical to
those of the conventional models.
0.4K to 55K,
according to
capacity
EMC Directive
compatible noise filer
(Note 3)
SF
Noise filer conforming to the EMC Directive (EN50081-2)
0.4 to 55K,
according to
capacity
High-duty brake
resistor
FR-ABR-(H)
(Note 1)
Used to improve the braking capability of the brake built in the
inverter.
0.4K to 7.5K,
according to
capacity
Surge voltage
suppressing filter
FR-ASF-H
Suppresses surge voltages on the inverter output side.
0.4 to 55K,
according to
capacity
Power factor improving
DC reactor
FR-BEL-(H)
(Note 1)
Used to improve the inverter input power factor (overall power
factor about 95%) and cooperate with the power supply.
0.4K to 55K,
according to
capacity
Power factor improving
AC reactor
FR-BAL-(H)
(Note 1)
Used to improve the inverter input power factor (overall power
factor about 90%) and cooperate with the power supply.
0.4K to 55K,
according to
capacity
Radio noise filter
FR-BIF-(H)
(Note 1)
For radio noise reduction
FR-BSF01
For line noise reduction (applies to small capacities of 3.7kW or
less)
Line noise filter
FR-BLF For line noise reduction
Common to
all models
BU brake unit
BU-1500 to 15K,
H7.5K to H30K
Used to improve the braking capability of the inverter (for high-
inertia load or negative load).
Brake unit
FR-BU-15K to 55K,
H15K to H55K
Resistor unit
FR-BR-15K to 55K,
H15K to H55K
Used to improve the braking capability of the inverter (for high-
inertia load or negative load). Use the brake unit and resistor unit
together.
Power return converter
FR-RC-15K to 55K,
H15K to H55K
High-function brake unit which can return motor-generated braking
energy to the power supply.
High power factor
converter
FR-HC7.5K to 55K,
H7.5K to H55K
The high power factor converter switches the converter circuit on-
off to convert the input current waveform into a sine wave to
suppress harmonics considerably. (Used with the standard
accessories.)
According to
capacity
Manual controller FR-AX (Note 4)
For independent operation. With frequency meter, frequency
setting potentiometer and start switch.
DC tach. follower FR-AL (Note 4)
For joint operation using external signals. (0 to 5VDC, 0 to 10VDC)
(1VA) (Note 2)
Three speed selector FR-AT (Note 4) For three-speed (high, middle, low) switching operation. (1.5VA)
Motorized speed setter FR-FK (Note 4)
For remote operation. Allows operation to be controlled from
several places. (5VA)
Ratio setter FR-FH (Note 4) For ratio control. Allows ratios to be set to five inverters. (3VA)
Common to
all models
