[Indoor unit – Model setting information] (Request code :"162")
Data display
00
See the table on the right.
Display Model setting state Display Model setting state
00 PSA-RP•GA, PSH-P•GAH 20
01 21
PKA-RP•FAL(2), PKH-P•FALH
02 PEAD-RP•EA(2)/GA, PEHD-P•EAH 22 PCA-RP•GA(2), PCH-P•GAH, PLA-RP•BA, PLA-RP71/100/125BA2
03 SEZ-KA•VA 23
04 24
05 SLZ-KA•VA(L) 25
06 PCA-RP•HA 26
07 27
08 28
09 29
0A 2A
0b 2b PKA-RP•GAL, PKH-P•GALH
0C 2C
0d 2d
0E 2E
0F 2F PLA-RP• AA
10 30
11 PEA-RP•EA 31 PLH-P•AAH
PLA-RP•AA2
12 MEXZ-GA•VA(L) 32
13 33
14 34
15 35
16 36
17 37
18 38
19 39
1A 3A
1b 3b
1C 3C
1d 3d
1E 3E
1F 3F
[Indoor unit – Capacity setting information] (Request code :"163")
Data display
00
See the table on the right.
Display Capacity setting state Display Capacity setting state
00 12 10 112
01 16 11 125
02 22 12 140
03 25 13 160
04 28 14 200
05 32 15 224
06 35, 36 16 250
07 40 17 280
08 45 18
09 50 19
0A 56 1A
0b 63 1b
0C 71 1C
0d 80 1d
0E 90 1E
0F 100 1F
Display Pair No. setting state
00 No. 0
01 No. 1 J41 disconnected
02 No. 2 J42 disconnected
03 No. 3 J41, J42 disconnected
[Wireless pair No. (indoor control board side) setting] (Request code :"165")
Data display
00
See the table on the right.
PCA-RP•KA
PKA-RP•HAL/KAL
PEAD-RP•JA(L)
PLA-RP100BA3, 140BA2
OCH415G
