Mitsubishi Electric PUHZ-P125YHA User Manual

35
10 REFRIGERANT SYSTEM DIAGRAM
Accumulator
Compressor
Refrigerant GAS pipe
15.88
mm(: 5/8)
Refrigerant LIQUID pipe
9.52
mm(: 3/8)
4-way
valve
Service port
(check)
High pressure protect switch
Linear expansion valve
Muffler
Thermistor
(TH4)
Stop valve
(#50)
Strainer
Strainer
(#100)
Strainer
(#100)
Stop valve
(with service port)
Strainer
(#40)
Thermistor (TH3)
Capillary tube
(
: 4.0% : 3.0%-L200)%2
Thermistor
(TH6)
Distributor
Bypass valve
Outdoor heat exchanger
Thermistor
(TH3)
Thermistor
(TH6)
Distributor
Service
port
(check)
Service
port
(check)
Accumulator
Compressor
Refrigerant GAS pipe
15.88mm(:5/8)
Refrigerant LIQUID pipe
9.52mm(:3/8)
Stop valve
(with service port)
4-way valve
Service
port
(check)
High pressure
protect switch
Linear expansion valve
Thermistor
(TH4)
Muffler
Stop valve
(#50)
Strainer
(#100)
Strainer
Strainer
(#40)
(#100)
Strainer
Refrigerant flow in cooling
Refrigerant flow in heating
Unit : mm (inch)
PUHZ-P100VHA2.UK
PUHZ-P100VHA3.UK
PUHZ-P100VHA3R1.UK
PUHZ-P125VHA2.UK PUHZ-P140VHA2.UK
PUHZ-P125VHA2
1
.UK PUHZ-P140VHA2
1
.UK
PUHZ-P125VHA3.UK PUHZ-P140VHA3.UK
PUHZ-P125VHA3R1.UK PUHZ-P140VHA3R1.UK
OCH415G
