21
A
Screen Assembly Removal -
Note: The Screen Assembly and screens are not considered to be field replaceable items.
1. Remove the COVER-FRONT.
2. Remove Screws (A) from the bottom front.
3. Remove Screws (B) from the rear sides.
4. Remove the Screen Assembly from the cabinet.
IMPORTANT: Do not allow the rear of the screen to come into contact with any other surface including clean-
ing cloths or fingers. Remove dust or other debris by blowing with a dry air source.
IMPORTANT: Do not disassemble the Screen Assembly.
B B
To Next Page
