(4) Electrical wiring
™ This air conditioning system should be notificated to supply authority before connection to power supply system.
(a) Selection of size of power supply and interconnecting wires.
IMPORTANT
¡ Electric wiring work should be conducted only by authorized personnel.
¡ Use copper conductor only.
¡ Power source wires and Interconnecting wires shall not be lighter than
polychloroprene sheathed flexible cord (design HO5RN-F IEC 57).
¡ Do not connect more than three wires to the terminal block.
¡ Use round type crimped terminal lugs with insulated grip on the end of the wires.
¡ Select wire sizes and circuit protection from Table 2.
Table 2 ( This table shows 20m length wires with less than 2% voltage drop. )
FDC508HES3 30 20 1.6mm
FDC808HES3 3
50 50
5.5mm
2
2.0mm
FDC1008HES3
Power source
wires
(minimum)
Interconnecting
and grounding
wires (minimum)
Over-current protector
rated capacity (A)
Switch breaker
(A)
Item
Model
Phase
Circuit breaker
1) For twin type
Outdoor Unit: FDC508HES3
Indoor Unit: FDT258-A + FDR258-A
Double twin specification (FDC808, 1008HES3 only)
G = main piping L (m) × C + branch piping L
1(m) × f + branch piping L2 (m) × f + branch piping 1 (m) × f
+ branch piping
2 (m) × f + branch piping 3 (m) × f + branch piping 4 (m) × f - (D - B)
Example of Calculation
8.0mm
2
FDC508
Outdoor unit Indoor unit
FDT258-A
FDR258-A
φ9.52
φ9.52
Liquid line φ9.52
Main piping L=30m
1=5m
2=5m
G=30m(L) × 0.035kg/m + 5m( 1) × 0.025kg/m + 5m( 2) × 0.025kg/m - (1.90 - 1.73)
=1.13kg
Amount of additional charge: 1.13 kg
Twin Type
FDC1008
Outdoor unit Indoor unit
FDT258-A
FDT258-A
FDR258-A
φ9.52
φ9.52
Liquid line φ15.88
Main piping L=20m L
1
=5m
4
=5m
FDR258-A
φ9.52
3
=5m
φ9.52
1
=5m
φ9.52
φ9.52
1
=5m
L
2
=5m
G=20m(L) × 0.07kg/m + 10m(L
1
+L
2
) × 0.025kg/m + 20(
1
+
2
+
3
+
4
) × 0.025kg/m
- (7.6 - 7.25)=1.8kg Amount of additional charge: 1.8 kg
Double twin Type
2) For double twin type
Outdoor Unit: FDC1008HES3
Indoor Unit: FDT258-A + FDT258-A + FDR258-A + FDR258-A
For recharging If vacuum extracted and recharging.
Twin & triple specifications
G = B + main piping L (m) × C + branch piping 1 × f + branch piping 2 (m) × f + branch piping 3 (m) × f
(only fortriple specifications)
Double twin specification (FDC808, 1008HES3 only)
G = main piping L (m) × C + branch piping L1(m) × f + branch piping L2 (m) × f + branch piping 1 (m) × f
+ branch piping
2 (m) × f + branch piping 3 (m) × f + branch piping 4 (m) × f
To Next Page
