1 GENERAL INFORMATION
1.1 Specific features
Ideal for the installation conditions characteristic of larger rooms and L-shaped or other non-standard-shaped rooms, the Multi-Type V
series allows an extensive degree of flexibility in the selection of indoor units. Specifically, the selection of indoor units with differing
capacities and differing or similar types is supported, as is the selection of indoor units with similar capacities and differing types.
Furthermore, a maximum of up to four individual indoor units can be operated in synchrony with a single outdoor unit.
(1) A new refrigerant, R410A, which causes no damage to the earth’s ozone layer, is used. R410A is a pseudoazeotropic refrigerant, so
there is little formation of separate vapor and liquid layers, and it is possible to add refrigerant on-site.
(2) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been
reduced by more than 50%.
(3) The microcomputer chip is installed in the indoor unit and outdoor unit. There is no need for the unit to communicate between the
outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction
has been reduced. The compressor in the outdoor unit has its own self protection function, that reacts according to abnormal high
pressure and excessive high temperature.
(4) There are only three power lines between the outdoor and indoor unit. One cabtyre cable with 3 wires encased in one sheath is
enough for conducting the wiring work between the outdoor unit and the indoor unit. This contributes to simpler wiring work in the
field.
(5) All air supply ports have auto swing louvers. (Only case of FDT, FDEN and FDKN models). The indoor fan motor has three speeds
of high, medium and low.
(6) All models have service valves protruding from the outdoor unit for faster flare connection (FDCA801, 1001: Only a gas side is
brazing) work in the field.
1.2 How to read the model name
Series No.
Product capacity
R410A models
Model name
FDT :
FDEN :
FDKN :
FDUR :
Celing recessed type unit with wired
remote controller
Celing suspension type unit with
wireless remote controller
Wall mounted type unit with wireless
remote controller
Ceiling mounted duct type unit with
wired remote controller
Example: FDC A 30 1 H EN
Applicable power source ... See the specifications
Heat pump type
Series No.
Product capacity
R410A models
Model name (FDC: Outdoor unit)
