FOR EMERGENCIES
8–25
D Some fuses may not be installed on
your vehicle, depending on the vehicle
model or specifications.
D The table above shows the main equip-
ment corresponding to each fuse.
N29C013a
Changing a fuse
EN29C - Ce
1. Before replacing a fuse, always turn
off the electrical circuit concerned and
turn the ignition key to the “LOCK”
position.
2. Remove the fuse box cover.
3. Referring to the fuse load capacity
table, check the fuse pertaining to the
problem.
A - Fuse is OK
B - Blown fuse
N29C008a
4. There is a fuse removing tool in the
fuse cover of the passenger com-
partement. First take the fuse remov-
ing tool out of the fuse cover slowly
and then by using the fuse removing
tool, pull the fuse straight out from the
fuse box. If it is not blown, something
else must be causing the problem;
contact an authorized MITSUBISHI
dealer to have the problem checked.
