INSTRUMENTS AND CONTROLS
4–2
T
ype 1
D01A231a
Instruments
ED01AMKb
1-
Fuel gauge
2-
Speedometer
3-
T
achometer*
4-
W
ater temperature gauge
5-
T
ripmeter reset button
6-
T
ripmeter
7-
Odometer
T
ype 2
D01A232a
T
ype 1
D03A082a
Speedometer
ED03A-Ca
T
ype 1
The
speedometer indicates
the
vehicle’
s
speed
in kilometres
per
hour
(km/h).
67
69
