Midband (66-88MHz) Controller_IO Schematic Diagram
5C.4-6 Diagrams and Parts Lists
Controller_IO
Parts List
R0209 0662057A73 10k 1/16W 5%
R0210 0662057A49 1k 1/16W 5%
R0220 0662057A77
0662057A84
15k 1/16W 5%
30k 1/16W 5%
R0221 0662057B47 0 1/16W
R0222 0662057A89 47k 1/16W 5%
R0223 0662057R92 47.5k .1W 1%
R0224 0662057A73 10k 1/16W 5%
R0225 0662057A83 27k 1/16W 5%
R0231 0662057B47 0 1/16W
R0232 0662057A93 68k 1/16W 5%
R0233 0662057A73 10k 1/16W 5%
R0235 0662057A85 33k 1/16W 5%
R0236 0662057A93 68k 1/16W 5%
R0251 0662057R92 47.5k .1W 1%
R0252 0662057R92 47.5k .1W 1%
U0101 5113802A48 PROC350 PLAT S/W
R010000 A3
U0102 5105625U73 IC 256K x 8 FLS ROM NIN
TSOP
U0103 5105662U54 HYBRID 32KX8 SRAM
TEST
U0104 5108444S49 IC 4Kx8 EEPROM
U0105 5113805A30 IC 10F8 DCDR/REMUX
74HC138
U0106 5105492X36 74AC08 4 AND GATES
U0201 5105835U45 ASFIC
U0202 5183222M49 IC QUAD OPAMP __3403_
U0251 5113818A03 IC High Performance SI
VR0101 4813830A23 10V 5% 20mA 350mW
VR0102 4813830A14 5.1V 5% 225mW
VR0161 4813830A15 5.6V 5% 225mW
Circuit
Ref
Motorola
Part No.
Description
Circuit
Ref
Motorola
Part No.
Description
C0401 2113743A19 100nF 16V
C0402 2113741F37 3.3nF 50V
C0404 2311049A99 TANT CP 47uF 20% 10V
C0405 2113741F25 1nF 50V
C0406 2113741F25 1nF 50V
C0407 2113741F49 10nF 50V
C0408 2113741F49 10nF 50V
C0409 2109720D14 CER LOW DIST 100nF
C0410 2113741F17 470pF 50V
C0412 2113741F17 470pF 50V
C0413 2113743E20 100nF 16V
C0414 2113741F33 2.2nF 50V X7R
C0415 2113741F17 470pF 50V
C0416 2113741F17 470pF 50V
C0417 2311049A57 TANT CP 10uF 10% 16V
C0418 2311049A05 TANT CP 470nF 10% 25V
C0419 2311049A99 TANT CP 47uF 20% 10V
C0421 2113741F17 470pF 50V
C0422 2113741F17 470pF 50V
C0423 2113741F17 470pF 50V
C0425 2113741F17 470pF 50V
C0426 2113741F17 470pF 50V
C0427 2113741F17 470pF 50V
C0431 2113741F17 470pF 50V
C0433 2113741F49 10nF 50V
C0441 2113741F17 470pF 50V
C0442 2113741F17 470pF 50V
C0451 2113741F17 470pF 50V
D0441 4813833C02 DUAL SOT MMBD6100
J0400 2804503J01 Accessory Connector 16 Pin
L0401 2484657R01 Ferrite Bead
L0402 2484657R01 Ferrite Bead
Q0401 4813824A10 NPN 40V .2A B=50-150
Q0411 4880052M01 NPN DRLNGTN MXTA
Q0431 4880048M01 NPN DIG 47k/47k
Q0432 4813824A10 NPN 40V .2A B=50-150
Q0441 4880048M01 NPN DIG 47k/47k
Q0450 4880048M01 NPN DIG 47k/47k
R0401 0662057A65 4k7 1/16W 5%
R0402 0662057A49 1k 1/16W 5%
R0404 0662057A73 10k 1/16W 5%
R0405 0662057A73 10k 1/16W 5%
R0406 0662057A81 22k 1/16W 5%
R0407 0662057A77 15k 1/16W 5%
R0411 0662057A73 10k 1/16W 5%
R0412 0662057A65 4k7 1/16W 5%
R0414 0662057A41 470 1/16W 5%
R0415 0662057A49 1k 1/16W 5%
R0416 0662057A25 100 1/16W 5%
R0417 0662057A97 100k 1/16W
R0418 0662057A43 560 1/16W 5%
R0419 0662057A97 100k 1/16W
R0420 0662057A35 270 1/16W 5%
R0421 0662057A43 560 1/16W 5%
R0422 0662057A35 270 1/16W 5%
R0423 0662057A65 4k7 1/16W 5%
R0424 0662057A35 270 1/16W 5%
R0425 0662057A09 22 1/16W
R0431 0662057A73 10k 1/16W 5%
R0432 0662057A65 4k7 1/16W 5%
R0433 0662057A65 4k7 1/16W 5%
R0435 0662057A73 10k 1/16W 5%
R0440 0662057A93 68k 1/16W 5%
R0441 0662057A65 4k7 1/16W 5%
Circuit
Ref
Motorola
Part No.
Description
R0442 0662057A73 10k 1/16W 5%
R0449 0662057A85 33k 1/16W 5%
R0450 0662057A65 4k7 1/16W 5%
R0451 0662057A65 4k7 1/16W 5%
U0401 5109699X01 AUDIO PA TDA1915C
VR0410 4813830A27 14V 5% 225mW
VR0412 4813830A40 SOC23 AUTO SDN
VR0415 4813830A27 14V 5% 225mW
VR0416 4813830A27 14V 5% 225mW
VR0420 4813830A15 5.6V 5% 225mW
VR0423 4813830A15 5.6V 5% 225mW
VR0425 4813830A15 5.6V 5% 225mW
VR0426 4813830A27 14V 5% 225mW
VR0427 4813830A27 14V 5% 225mW
VR0431 4813830A27 14V 5% 225mW
VR0441 4813830A40 SOC23 AUTO SDN
VR0451 4813830A15 5.6V 5% 225mW
Circuit
Ref
Motorola
Part No.
