Midband (66-88MHz) Supply Voltage Schematic Diagram
5C.4-40 Diagrams and Parts Lists
Supply Voltage
Parts List
Circuit
Ref
Motorola
Part No.
Description
C0601 2113741F17 470pF 50V
C0602 2113741B69 100nF 50V
C0603 2380090M24 LYT 10uF 50V 20%
C0604 2311049A97 TANT CHIP 33 UF 16
C0605 2113743E20 100nF 16V
C0611 2311049A99 TANT CP 47uF 20% 10V
C0613 2113741F17 470pF 50V
C0621 2113741F17 470pF 50V
C0622 2311049A99 TANT CP 47uF 20% 10V
C0631 2113743E20 100nF 16V
C0632 2311049A97 TANT CHIP 33 UF 16
C0633 2113743E07 22nF 16V
C0634 2311049A99 CP 47uF 20% 10V
C0635 2113743E20 100nF 16V
C0641 2113743E20 100nF 16V
D0611 4813833C02 DUAL SOT MMBD6100
D0621 4813833C02 DUAL SOT MMBD6100
D0631 4813833C02 DUAL SOT MMBD6100
Q0601 4813824A10 NPN 40V .2A B=50-150
Q0611 4805921T02 DUAL ROHM FMC2 RH
R0601 0662057A73 10k 1/16W 5%
R0602 0660076E70 FILM 7500 1 1
R0603 0660076E51 FILM 1200 1 1
R0604 0662057A49 1k 1/16W 5%
R0605 0662057A69 6k8 1/16W 5%
R0606 0662057B47 0 1/16W
R0614 0662057A49 1k 1/16W 5%
R0621 0662057A57 2k2 1/16W 5%
R0631 0662057A01 10 1/16W 5%
R0632 0662057A01 10 1/16W 5%
R0641 0662057A84 30k 1/16W 5%
R0642 0662057A73 10k 1/16W 5%
U0601 5105625U25 IC 9.3V REG 2941
U0631 5105469E65 IC VLTG REGLTR LP2951C
VR0621 4813830A14 5.1V 5% 225mW
VR0641 4813830A14 5.1V 5% 225mW
Circuit
Ref
Motorola
Part No.
Description
