Motorola GM-950 User Manual

Midband (66-88MHz) Synthesizer Schematic Diagram
5C.4-14 Diagrams and Parts Lists
Synthesizer
Parts List
Circuit
Ref
Motorola
Part No.
Description
C2701 2113740F51 100pF 5% 50V
C2702 2113741F13 330pF 50V
C2703 2113743E20 100nF 16V
C2704 2113741F49 10nF 50V
C2705 2113741F49 10nF 50V
C2706 2113743E20 100nF 16V
C2707 2113741F49 10nF 50V (12.5kHz)
2113743E07 22nF 50V (20/25kHz)
C2709 2113743E20 100nF 16V
C2711 2311049A63 TANT CP 10uF 10% 10V
C2712 2311049J26 TANT CP 10uF 20% 16V
C2713 2113741F25 1nF 50V
C2715 2113740F39 33pF 5% 50V
C2716 2113743E20 100nF 16V
C2717 2113743E20 100nF 16V
C2718 2113743E20 100nF 16V
C2719 2311049A19 TANT CP 10uF 10% 25V
C2720 2113741F49 10nF 50V
C2722 2311049A07 TANT CP 1uF 10% 16V
C2723 2109720D14 CER LOW DIST 100nF
C2725 2109720D14 CER LOW DIST 100nF
C2726 2113741F49 10nF 50V
C2727 0811051A19 MTLZ POLY 1uF 5%
D2701 4802233J09 DIODE TRIPLE SOT143-RH
E2702 2605915V01 SHLD PCB MOUNT 1
R2701 0662057A35 270 1/16W 5%
R2702 0662057A35 270 1/16W 5%
R2703 0662057A49 1k 1/16W 5%
R2705 0662057A89 47k 1/16W 5%
R2708 0662057A01 10 1/16W 5%
R2709 0662057A01 10 1/16W 5%
R2711 0662057A25 100 1/16W 5%
R2712 0662057A59 2k7 1/16W 5%
R2713 0662057A59 2k7 1/16W 5% (12.5kHz)
R2714 0662057B02 150k 1/16W
R2715 0662057A41 470 1/16W 5%
R2716 0662057A43 560 1/16W 5%
R2717 0662057A25 100 1/16W 5%
R2718 0662057A25 100 1/16W 5%
R2723 0662057A73 10k 1/16W 5%
R2724 0662057B14 470k 1/16W 5%
U2701 5105457W72 CC QFP CONT FRAC-N
VR2701 4813830A23 Diode 10V 5% 20mA 350mW
Y2702 4809863M01 REF OSC 16.8MHz Tempus
Circuit
Ref
Motorola
Part No.
Description
