Motorola GM-950 User Manual

Midband (66-88MHz) Controller Schematic Diagram
5C.4-34 Diagrams and Parts Lists
Controller
Parts List
Circuit
Ref
Motorola
Part No.
Description
C0100 2113741F17 CHIP 470pF 50V
C0101 2113743E20 CHIP 100nF 16V
C0102 2113741F17 CHIP 470pF 50V
C0103 2113741F17 CHIP 470pF 50V
C0104 2113741F49 CHIP 10nF 50V
C0105 2311049A42 TANT CP 3.3uF 10% 6V
C0106 2113743E20 CHIP 100nF 16V
C0107 2113741F49 CHIP 10nF 50V
C0108 2113741F25 CAP CHIP 1nF 50V
C0109 2113741F17 CAP CHIP 470pF 50V
C0110 2113741F17 CAP CHIP 470pF 50V
C0111 2113741F49 CAP CHIP 10nF 50V
C0112 2113741F49 CAP CHIP 10nF 50V
C0113 2113741F49 CAP CHIP 10nF 50V
C0114 2113741F49 CAP CHIP 10nF 50V
C0121 2113741F49 CAP CHIP 10nF 50V
C0131 2113743E20 CAP CHIP 100nF 16V
C0132 2311049A07 CAP TANT CP 1uF 10% 16V
C0133 2113743E20 CAP CHIP 100nF 16V
C0135 2113743E20 CAP CHIP 100nF 16V
C0136 2113741F17 CAP CHIP 470pF 50V
C0141 2113741F17 CAP CHIP 470pF 50V
C0150 2113741F17 CAP CHIP 470pF 50V
C0151 2113743E20 CAP CHIP 100nF 16V
C0152 2113741F17 CAP CHIP 470pF 50V
C0153 2113741F17 CAP CHIP 470pF 50V
C0154 2113741F17 CAP CHIP 470pF 50V
C0155 2113741F17 CAP CHIP 470pF 50V
C0156 2113741F17 CAP CHIP 470pF 50V
C0157 2113741F17 CAP CHIP 470pF 50V
C0158 2113741F17 CAP CHIP 470pF 50V
C0159 2113741F17 CAP CHIP 470pF 50V
C0161 2113741F17 CAP CHIP 470pF 50V
C0162 2113741F17 CAP CHIP 470pF 50V
C0163 2113741F17 CAP CHIP 470pF 50V
C0164 2113741F17 CAP CHIP 470pF 50V
C0171 2113743E20 CAP CHIP 100nF 16V
C0172 2113743E20 CAP CHIP 100nF 16V
C0200 2113743E20 CAP CHIP 100nF 16V
C0201 2113741F17 CAP CHIP 470pF 50V
C0202 2113741F17 CAP CHIP 470pF 50V
C0203 2113741F17 CAP CHIP 470pF 50V
C0204 2113741F17 CAP CHIP 470pF 50V
C0205 2113743F08 CAP CHIP 220nF 5% 50V
C0206 2113743E20 CAP CHIP 100nF 16V
C0207 2113743F08 CAP CHIP 220nF 5% 50V
C0208 2113741F13 CAP CHIP 330pF 50V
C0209 2311049J26 TANT CP 10uF 20% 16V
C0210 2113741M53 CAP CHIP 22nF 50V
C0211 2113743A19 CAP CHIP 100nF 16V
C0212 2113743E20 CAP CHIP 100nF 16V
C0221 2113743E20 CAP CHIP 100nF 16V
C0222 2311049A07 CAP TANT CP 1uF 10% 16V
C0223 2113741A57 CAP CHIP 33nF 50V
C0224 2311049J11 TANT CP 4.7uF 10% 16V
C0225 2113741F49 CAP CHIP 10nF 50V
C0226 2113743E20 CAP CHIP 100nF 16V
C0227 2311049A99 TANT CP 47uF 20% 10V
C0228 2311049A01 TANT CP 100nF 10% 35V
C0229 2113741F49 CAP CHIP 10nF 50V
C0230 2311049J23 CAP TANT CP 10uF 10% 6V
C0231 2113741F49 CAP CHIP 10nF 50V
C0233 2113740F39 CAP CHIP 33pF 5% 50V
C0234 2113743E20 CAP CHIP 100nF 16V
Circuit
Ref
Motorola
Part No.
Description
C0235 2113743A19 CAP CHIP 100nF 16V
C0242 2113741F17 CAP CHIP 470pF 50V
C0246 2113740F36 CAP CHIP 24pF 5% 50V
C0251 2113743E20 CAP CHIP 100nF 16V
C0252 2311049J23 CAP TANT CP 10uF 10% 6V
C0253 2311049A07 CAP TANT CP 1uF 10% 16V
C0254 2113743E20 CAP CHIP 100nF 16V
C0401 2113743A19 CAP CHIP 100nF 16V
C0402 2113741F37 CAP CHIP 3.3nF 50V
C0404 2311049A99 TANT CP 47uF 20% 10V
C0405 2113741F25 CAP CHIP 1nF 50V
C0406 2113741F25 CAP CHIP 1nF 50V
C0407 2113741F49 CAP CHIP 10nF 50V
C0408 2113741F49 CAP CHIP 10nF 50V
C0409 2109720D14 CAP CER LOW DIST 100nF
C0410 2113741F17 CAP CHIP 470pF 50V
C0412 2113741F17 CAP CHIP 470pF 50V
C0413 2113743E20 CAP CHIP 100nF 16V
C0414 2113741F33 CAP CHIP 2.2nF 50V
C0415 2113741F17 CAP CHIP 470pF 50V
C0416 2113741F17 CAP CHIP 470pF 50V
C0417 2311049A57 TANT CP 10uF 10% 16V
C0418 2311049A05 TANT CP 470nF 10% 25V
C0419 2311049A99 TANT CP 47uF 20% 10V
C0421 2113741F17 CAP CHIP 470pF 50V
C0422 2113741F17 CAP CHIP 470pF 50V
C0423 2113741F17 CAP CHIP 470pF 50V
C0425 2113741F17 CAP CHIP 470pF 50V
C0426 2113741F17 CAP CHIP 470pF 50V
C0427 2113741F17 CAP CHIP 470pF 50V
C0431 2113741F17 CAP CHIP 470pF 50V
C0433 2113741F49 CAP CHIP 10nF 50V
C0441 2113741F17 CAP CHIP 470pF 50V
Circuit
Ref
Motorola
Part No.
Description
C0442 2113741F17 CAP CHIP 470pF 50V
C0451 2113741F17 CAP CHIP 470pF 50V
D0101 4813833C02 DUAL SOT MMBD6100
D0102 4813833C02 DUAL SOT MMBD6100
D0200 4813833C02 DUAL SOT MMBD6100
D0441 4813833C02 DUAL SOT MMBD6100
D0481 4813833C02 DUAL SOT MMBD6100
D0482 4813833C02 DUAL SOT MMBD6100
J0101 0902636Y01 Connector Flex Side Entry
J0102 0904424J03 Connector 8 POS SMD T&R
J0103 0904424J03 Connector 8 POS SMD T&R
J0400 2804503J01 CONNECTOR ACCY 16 PIN
L0131 2462587Q40 COIL CHIP 270nH
L0132 2462587Q40 COIL CHIP 270nH
L0200 2462587K26 CHIP IND 33000 NH
L0401 2484657R01 Ferrite Bead
L0402 2484657R01 Ferrite Bead
Q0101 4880048M01 TSTR NPN DIG 47k/47k
Q0102 4880048M01 TSTR NPN DIG 47k/47k
Q0103 4880048M01 TSTR NPN DIG 47k/47k
Q0104 4880048M01 TSTR NPN DIG 47k/47k
Q0105 4813824A10 NPN 40V .2A B=50-150
Q0106 4880048M01 TSTR NPN DIG 47k/47k
Q0121 4880048M01 TSTR NPN DIG 47k/47k
Q0122 4880048M01 TSTR NPN DIG 47k/47k
Q0123 4880048M01 TSTR NPN DIG 47k/47k
Q0124 4880048M01 TSTR NPN DIG 47k/47k
Q0125 4880048M01 TSTR NPN DIG 47k/47k
Q0141 4880048M01 TSTR NPN DIG 47k/47k
Q0171 4880048M01 TSTR NPN DIG 47k/47k
Q0200 4813824A10 NPN 40V .2A B=50-150
Q0401 4813824A10 NPN 40V .2A B=50-150
Q0411 4880052M01 NPN DRLNGTN MXTA
Circuit
Ref
Motorola
Part No.
Description
