Motorola GM-950 User Manual

Midband (66-88MHz) RX-IF Schematic Diagram
5C.4-20 Diagrams and Parts Lists
RX-IF
Parts List
Circuit
Ref
Motorola
Part No.
Description
C2200 2113740F31 15pF 5% 50V (12.5kHz)
2113740F33 18pF 5% 50V (20/25kHz)
C2202 2113740F45 56pF 5% 50V (12.5kHz)
2113740F36 24pF 5% 50V (20/25kHz)
C2203 2113743A19 100nF 16V
C2204 2113743A19 100nF 16V
C2205 2113740F42 43pF 5% 50V (12.5kHz)
2113740F31 15pF 5% 50V (20/25kHz)
C2207 2113740F45 56pF 5% 50V (12.5kHz)
2113740F43 47pF 5% 50V (20/25kHz)
C2210 2113740F38 30pF 5% 50V (12.5kHz)
2113740F45 56pF 5% 50V (20/25kHz)
C2211 2113740F29 12pF 5% 50V (12.5kHz)
2113740F26 9.1pF 5% 50V (20/25kHz)
C2212 2113740F63 330pF 5% 50V
C2213 2113740F37 27pF 5% 50V
C2214 2113740F11 2.2pF 5% 50V
C2215 2113743A23 220nF 16V
C2216 2113743A23 220nF 16V
C2220 2113741F49 10nF 50V
C2221 2311049A63 TANT CP 10uF 10% 10V
C2222 2113743A23 220nF 16V
C2223 2113743E20 100nF 16V
C2224 2113741F29 1.5nF 50V
C2225 2311049J11 TANT CP 4.7uF 10% 16V
C2226 2113743K07 47nF 16V (12.5kHz)
2113743K15 100nF 16V (20/25kHz)
C2227 2311049J11 TANT CP 4.7uF 10% 16V
C2228 2113743E20 100nF 16V
C2229 2113741F41 4.7nF 50V (12.5kHz)
2113741F25 1nF 50V (20/25kHz)
C2230 2113741F49 10nF 50V
C2231 2311049A07 TANT CP 1uF 10% 16V
C2232 2113740F51 100pF 5% 50V
C2233 2113740F51 100pF 5% 50V
C2234 2113743E20 100nF 16V
C2235 2113740F51 100pF 5% 50V
C2236 2113740F51 100pF 5% 50V
C2237 2113743E20 100nF 16V
C2238 2113743E20 100nF 16V
C2239 2113740F44 51pF 5% 50V
D2201 4880154K03 DIODE DUAL SCHOTTKY
D2202 4880154K03 DIODE DUAL SCHOTTKY
FL2201 9180098D06 FILTER CER 4-EL 455kHz
FL2202 9180097D06 FILTER CER 6-EL 455kHz
L2201 2462587M23 CHIP IND 2.7uH 5%
L2203 2462587M23 CHIP IND 2.7uH 5%
Q2201 4813827A07 TSTR NPN SML SIG
MMBR9
R2201 0662057A73 10k 1/16W 5%
R2202 0662057A85 33k 1/16W 5%
R2203 0662057A69 6k8 1/16W 5%
R2204 0662057A25 100 1/16W 5%
R2205 0662057A56 2k 1/16W 5%
R2206 0662057A01 10 1/16W 5%
R2211 0662057B47 0 1/16W
R2212 0662057A55 1k8 1/16W 5%
R2216 0662057A73 10k 1/16W 5% (12.5kHz)
0662057A69 6k8 1/16W 5% (20/25kHz)
R2221 0662057B02 150k 1/16W (12.5kHz)
0662057B05 200k 1/16W (20/25kHz)
R2222 0662057A93 68k 1/16W 5%
R2223 0662057A69 6k8 1/16W 5% (12.5kHz)
0662057A63 3k9 1/16W 5% (20/25kHz)
Circuit
Ref
Motorola
Part No.
Description
R2224 0662057A76 13k 1/16W 5%
R2225 0662057A25 100 1/16W 5% (12.5kHz)
0662057A61 3k3 1/16W 5% (20/25kHz)
U2201 5180207R01 IF IC
Y2201 4886022B01 X-TAL FILTER 21.4 12.5 HI
4886022B03 X-TAL FILTER 21.4 25 HI
Y2202 4886022B02 X-TAL FILTER 21.4 12.5 STD
4886022B04 X-TAL FILTER 21.4 25 STD
Y2211 4886058B01 X-TAL 20.945 MHz
Circuit
Ref
Motorola
Part No.
Description
