Motorola GM-950 User Manual

Midband (66-88MHz) Power Control Schematic Diagram
5C.4-24 Diagrams and Parts Lists
Power Control
Parts List
Circuit
Ref
Motorola
Part No.
Description
C0701 2113740F51 100pF 5% 50V
C0702 2113740F51 100pF 5% 50V
C0703 2113743K15 100nF 16V
C0711 2113741A59 CL2
C0712 2113740F42 43pF 5% 50V
C0713 2113740F51 100pF 5% 50V
C0714 2113743A19 100nF 16V
C0716 2113741F33 2.2nF 50V
C0721 2113740F51 100pF 5% 50V
C0722 2113740F51 100pF 5% 50V
C0723 2113740F51 100pF 5% 50V
C0731 2113743K15 100nF 16V
C0732 2113740F51 100pF 5% 50V
C0733 2113743A23 220nF 16V
C0738 2113743A23 220nF 16V
C0741 2113740F51 100pF 5% 50V
C0742 2113743K15 100nF 16V
D0721 4813833C02 DUAL SOT MMBD6100
D0731 4813833C02 DUAL SOT MMBD6100
D0732 4813833C02 DUAL SOT MMBD6100
D0733 4813833C02 DUAL SOT MMBD6100
Q0711 4813824A10 NPN 40V .2A B=50-150#
Q0731 4880048M01 NPN DIG 47k/47k
Q0732 4805921T02 DUAL ROHM FMC2
Q0741 4880048M01 NPN DIG 47k/47k
Q0742 4805128M27 PNP SOT89 BSR33 LH
R0701 0662057A73 10k 1/16W 5%
R0702 0662057A73 10k 1/16W 5%
R0703 0662057A61 3k3 1/16W 5%
R0704 0662057A97 100k 1/16W 5%
R0711 0662057A81 22k 1/16W 5%
R0712 0662057A37 330 1/16W 5%
R0713 0662057A61 3k3 1/16W 5%
R0714 0662057A81 22k 1/16W 5%
R0715 0662057A81 22k 1/16W 5%
R0716 0662057B16 560k 1/16W 5%
R0717 0662057A85 33k 1/16W 5%
R0718 0662057A93 68k 1/16W 5%
R0719 0662057A93 68k 1/16W 5%
R0721 0662057A73 10k 1/16W 5%
R0722 0662057A81 22k 1/16W 5%
R0723 0662057A89 47k 1/16W 5%
R0724 0662057B02 150k 1/16W
R0725 0662057A73 10k 1/16W 5%
R0731 0662057A73 10k 1/16W 5%
R0732 0662057A65 4k7 1/16W 5%
R0733 0662057A89 47k 1/16W 5%
R0734 0662057A65 4k7 1/16W 5%
R0735 0662057A73 10k 1/16W 5%
R0736 0662057A77 15k 1/16W 5%
R0738 0662057A89 47k 1/16W 5%
R0741 0662057A49 1k 1/16W 5%
R0742 0662057A49 1k 1/16W 5%
U0701 5183222M49 IC QUAD OPAMP __3403_
U0731 5113811G02 IC D/A CONV & BIT 4 CHAN
W/SPI
Circuit
Ref
Motorola
Part No.
Description
