2-12 Mechanical View and Parts List
Item
Part
Number
Description
1 DS1M001110 Front Cover Kit
2 DS1M001120 Chassis Hardware Kit
2a Rod (M2)
2b Heatsink Tape
2c Gasket (Screw M2.6)
2d Screw M2.6
2e PCB Bracket
2f Screw M2 CÞms
2g External Tape
3 DS1M001130 Knob Assembly
3a Knob
3b Spring (D4.75)
4 DS1M001140 External Cover Kit
4a External Cover
4b External Cover Cap
5 DS1M001150 Controller Board Assembly
6 DS1M001160 RF Board Assembly
7 DS1M001170 LCD Kit
7a LCD Bracket
7b LCD
7c Interconnector
7d Reßector
8 DS1M001180 Label Kit
8a Label (Nameplate)
8b Label (Serial)
8c Label (Tuning)
9 DS1M001190 Speaker Assembly
10 PMNN4046 Battery
11 DSM2192004 Contact Gasket
12 DSM2192005 Main Gasket
