37
PROGRAMMING FEATURES
both the PTT and the SB1 button simultaneously for 3
to 5 seconds while turning ON the radio until you hear
an audible voice saying “Programming Mode” and
“Channel Number”. The LED Indicator starts blinking a
green heartbeat.
Note: ‘Idle’ Programming Mode is the stage in the
Programming Mode where the radio waits
for the user to start the radio programming
cycle.
Once you are in the ‘Idle’ Programming Mode, you will
be able to hear the Frequencies, Codes, Auto-Scan,
Active Channels and Weather Channel settings by
short pressing the PTT button to navigate along the
different programmable features.
ENTERING FREQUENCIES VALUES
RDU4100 has 89 frequencies, 27 frequencies for
RDV5100 and 2 for RDU4103.
• In ‘Idle’ Programming mode, the Channel number
becomes the first changeable value. Select the
desired channel by turning the Channel Selector
Knob. An audible voice indicated the selected
channel to configure. Short pressing the PTT
button allows you to cycle through the other
features available for configuration. Use the SB1
and SB2 button to change the values. An audible
voice indicates the value selected.
READING CTCSS/DPL VALUES
Cycle through the features available for configuration
by short pressing the PTT button until you hear the
current code. The radio moves to the programming
CTCSS/PL codes mode.
Enter a new code value using the SB1 and SB2
buttons.
The RDX Series radios have up to 219 codes
available. For more information, refer to “Frequency
and Code Charts” on page 64.
READING AUTO-SCAN VALUES
After hearing the CTCSS/DPL codes, short pressing
the PTT button moves you to Auto- Scan mode.
Auto-Scan has only two values:
• Enabled
• Disabled
MN002895A01_final.book Page 37 Thursday, January 5, 2017 10:51 AM
