SATA1~6: SATA 6Gb/s 󳱥󲵑

󸶰󱛪󳱥󲵑󴂞 SATA 6Gb/s 󱜾󹪸󸷏󳰛󲘸󾗘󴪇󱤱󳱥󲵑󵵝󱿔󸷏󳰛󱘈󱤱 SATA 󸄅 󶷉󾗘

SATA3

SATA5

SATA4

SATA1

SATA2

SATA6

󹄟󸉕

SATA 󳯷󶬢󱘗󱿔󳶒󵭶󸤥󸸶 90 󳍿󾗚󱝤󱭾󱩥󸯳󸠜󳾓󴂹󵫕󵫑󹏌󸑱󾗘

SATA 󳯷󶬢󱮮󶔏󳰛󹰈󲡌󸊻󵸒󱟣󾗚󳐫󸘟󲻀󳌣󹰈󶔏󳰛󱳭󱙛󴟆󴋃󾗚󱝤󶚰󵸢󶐁󹞇󾗘

JFP1, JFP2: 󶥛󶩂󹪸󴋃󳰛󹰈

󸶰󱛪󳰛󹰈󵫞󳿕󸷏󳰛󱴚󹪸󴋃󵵙󹝻󹠁󲃅 LED 󳬙󶆻󵓻

2 10

JFP1

1 HDD LED + 2 Power LED +

3 HDD LED - 4 Power LED -

5 Reset Switch 6 Power Switch

7 Reset Switch 8 Power Switch

9 Reserved 10 No Pin

JFP2

1 Speaker - 2 Buzzer +

3 Buzzer - 4 Speaker +

HDD LED

RESET SW

HDD LED

HDD LED -

HDD LED +

POWER LED -

POWER LED +

POWER LED

JFP1
