MSI B360M PRO-VH User Manual

13
I/O I/O
JAUD1: 
󳰙󶪓
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection
JCOM1: 
󱝑󳰛󶪔
1
2 10
9
1 DCD 2 SIN
3 SOUT 4 DTR
5 Ground 6 DSR
7 RTS 8 CTS
9 RI 10 No Pin
EZ Debug LED
LED󸀭󶆺
CPU - CPU󴕼󱲡󸑃󸗰󲢀󳼢󶆻
DRAM - DRAM󴕼󱲡󸑃󸗰󲢀󳼢󶆻
VGA - GPU󴕼󱲡󸑃󸗰󲢀󳼢󶆻
BOOT - 󴕼󱲡󸑃󸗰󲢀󳼢󶆻

MSI B360M PRO-VH Specifications

General

Form Factor	Micro-ATX
Chipset	Intel B360
Socket	LGA 1151
Memory Slots	2 x DIMM
Maximum Memory	32 GB
PCIe x16 Slots	1
M.2 Slots	1
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
RAID Support	No
Memory Speed	DDR4-2666/2400/2133 MHz
SATA Ports	4 x SATA 6Gb/s
USB 2.0 Ports	4
PCIe x1 Slots	2
