Block Diagram
Block Diagram
2 x USB 3.1 Gen1
2 Channel DDR4 Memory
1 x M.2
4 x USB 2.0
PCI Express Bus
PS/2 Mouse / Keyboard
Audio Jacks
CHIPSET
CPU
NV6795
Super I/O
Realtek
ALC887
PCI Express Bus
HDMI DisplayPort
4x SATA 6Gb/s
4 x USB 3.1 Gen1
