6-8
MS-7145 M-ATX Mainboard
Using Multiple Displays
Setting Up Multiple Displays
To use SURROUNDVIEW™, connect display devices to the output connections of
both your integrated graphics processor (IGP) and your PCI Express® graphics card.
There will normally be three connections: one from the IGP and two from the graphics
card.
u To connect your monitors
1. Power off your computer and monitors.
2. Plug the monitor cables into their appropriate connectors.
3. Power on your monitors first, and then restart your computer so that Win-
dows® can detect the new hardware settings.
Once your monitors are connected, you can configure them for a multi-monitor dis-
play using SURROUNDVIEW™.
Windows
®
Display Properties Dialog with Multiple Monitors
