2-5
Hardware Setup
Installing AMD Athlon64 CPU Cooler Set
When you are installing the CPU, make sure the CPU has a heat sink and
a cooling fan attached on the top to prevent overheating. If you do not have
the heat sink and cooling fan, contact your dealer to purchase and install them before
turning on the computer.
1.Detach the shield of the
backplate’s paster.
2.Turn over the mainboard, and
install the backplate to the
proper position.
3.Turn over the mainboard
again and place the
mainboard on the flat surface.
Locate the two screw holes
of the mainboard.
4.Align the retention mechanism
and the backplate. Fix the re-
tention mechanism and the
backplate with two screws.
retention mechanism
To Next Page
