MSI RS480M User Manual

2-2
MS-7145 M-ATX Mainboard
W83627THF
Quick Components Guide
DDR DIMMs, p.2-7
Back Panel
I/O, p.2-10
JPW1, p.2-9
IDE1/2, p.2-16
ATX1, p.2-9
CPUFAN1, p.2-15
FDD1, p.2-15
SYSFAN1,
p.2-15
J1394_1, p.2-21
PCI Express
Slot, p.2-24
PCI Slots,
p.2-24
JAUDIO1,
p.2-18
JSP1, p.2-19
JFP1,
p.2-20
JCASE1,p.2-21
JUSB1, JUSB2, p.2-20
SATA1~4,
p.2-13
JFP2,
p.2-20
CPU, p.2-3
JIR1, p.2-19
JCD_IN1, p.2-19
JBAT1, p.2-23
JTV1,
p.2-22
JBIOS_WP1,
p.2-23
