NAD T 777 User Manual

Until now, analogue radio signals such as FM or AM have been subject to
numerous kinds of interference on their way from the transmitter to your
radio. These problems were caused by mountains, high-rise buildings
and weather conditions. With Digital Audio Broadcast (DAB), you can now
receive CD-like quality radio programs without any annoying interference
and signal distortion. DAB broadcasts use digital signals rather than
traditional analogue transmissions, thus providing clear high quality
reception. You get far more robust reception and virtually hiss or crackle
free sound with DAB as long as you are within a good coverage area.
With DAB, the listener can scroll through a list of available stations - then
instantly tune to the station of his choice. There is no need to remember
channel frequencies. All broadcasts are selected by simply selecting the
service name.
The T 777 makes it possible for you to enjoy listening to DAB broadcasts.
The T 777 has a Digital Audio Broadcast (DAB) module socket on the rear
panel for adding a separately sold and NAD-specied outboard DAB
module - the NAD DAB Adaptor DB 1 or the DAB+ NAD DAB Adaptor
DB 2. All the control software for this format is included; just plug-in the
module and start enjoying the CD-like quality sound and expansive content
selection available with DAB.
IMPORTANT NOTES
r 5IF5JTDPNQBUJCMFPOMZXJUIUIF/"%%"#"EBQUPSNPEVMFNPEFMT
DB 1 or DB 2.
r 8IFOVTJOHUIF)53SFNPUFDPOUSPMUPDBSSZPVU%"#DPNNBOET
ensure that the DEVICE SELECTOR is set to “TUNER”.
r *OUIF%"#EJTDVTTJPOTCFMPXBMMDPOUSPMCVUUPOTNFOUJPOFEBSFXJUI
reference to the HTR 8 remote control.
CONNECTING THE DAB MODULE
Plug-in the other end of the DIN connector (supplied with your NAD DAB
Adaptor DB) from the DAB module’s output port into the corresponding
DAB module input socket on the rear panel of the T 777. Select DAB mode
on the T 777 by toggling HTR 8’s [AM/FM/DB] button.
NOTES
r 5IF/"%%"#"EBQUPS%#PS%#JTOPUTVQQMJFEXJUIZPVS5
r 3FGFSUPUIFJOTUBMMBUJPOEJBHSBNQSJOUFEPOUIFDBSUPOCPYPGUIF/"%
DAB Adaptor for guidance on how to connect the NAD DAB Adaptor to
the T 777.
r *GUIFSFJTOP/"%%"#"EBQUPSDPOOFDUFEUIF7'%XJMMTIPXi$IFDL
DAB Tuner”.
DAB OPERATION
With the separately sold NAD DAB Adaptor already connected to the T 777,
you can now carry out the T 777 to receive DAB broadcasts.
1 Toggle [AM/FM/DB] button until DAB mode. The VFD will show “No
Service List” indicating that there are no scanned DAB broadcast
services yet. This is the default mode of the NAD DAB Adaptor.
DAB P--
No Service List
2 To tune to DAB broadcast services, press [TUNER MODE] and then
toggle [ A/S ] to select either “Full Scan” or “Local Scan”.
FULL SCAN will enable the scanning of the full range of digital
frequencies (Band III and L-Band).
LOCAL SCAN performs local scanning of available DAB services in your
area. Check with your dealer or visit www.WorldDAB.org to check the
applicable digital transmission frequencies in your area.
3 Upon selecting either “Full Scan” or “Local Scan”, automatic scanning
will be performed. This sequence cannot be interrupted. During the
sequence, the following message will be visible in the VFD.
The bars show the progress of the sequence. When scanning is
completed, the last number shown on the right side of the VFD
corresponds to the total number of DAB broadcast stations found. Then,
the rst station is tuned in (See “ALPHANUMERIC” section below to
understand the order or arrangement of stations).
Scanning... 19
||||||||||||
OPERATION
LISTENING TO DAB RADIO
35
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

NAD T 777 Specifications

General

Receiver type	Surround
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (4 Ohm)	260 W
Dynamic power per channel (8 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
S-Video inputs quantity	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
AM band range	522 - 1.620 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LED
Product color	Black
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Package weight	24200 g

Weight and Dimensions

Depth	425 mm
Width	435 mm
Height	172 mm
Weight	20500 g
