NAD T 777 User Manual

USB INTERFACE
The HTR 8 allows one to upload and download the conguration through
a Windows
®
PC and NAD’s Proprietary HTR 8 programming software. Use
a USB A male to mini USB B male 5-pin cable (not supplied) between your
Windows
®
PC and the HTR 8. See illustration below on how to connect a
USB A male to mini USB B male 5-pin cable to the HTR 8.
NOTE
Please log onto www.nadelectronics.com/HTR8 for the latest HTR 8
interface control software. Your custom installer or dealer can assist
you in the proper setup and conguration of the mini USB interface and
software.
SLEEP MODE
The Sleep Mode timer will switch the T 777 to Standby mode automatically
after a preset number of minutes. Pressing the HTR 8’s SLEEP button once will
display the setting of the sleep time increment. Pressing the HTR 8’s SLEEP
button a second time within a 3-second period will change the sleep time
increment in 15-minute intervals, after which time the T 777 will automatically
switch into Standby mode.
To adjust the sleep delay, press the HTR 8’s SLEEP button twice; rst to
display the sleep time increment, and a second time to change the
sleep time increment. The sleep time increment and a “SLEEP” icon will
continuously display on the T 777’s front panel Vacuum Fluorescent Display
(VFD). Each consecutive press increases the sleep time in 15-minute
increments from 15 to 90 minutes. To cancel the sleep mode, continue
pressing the HTR 8’s SLEEP button until “Sleep O” displays on the VFD.
Switching the T 777 to standby from either the HTR 8’s OFF or the T 777’s
STANDBY button will also cancel the sleep mode
USING THE ZR 7 REMOTE CONTROL
The ZR 7 is a discrete compact remote for controlling the Zone 2 feature of the
T 777. Irrespective of the main room/zone settings, the ZR 7 allows full separate
control of the Zone 2 source selection among other applicable features.
1 ON/OFF: Switch ON/OFF the Zone feature.
2 SOURCE [ d/f ]: Select the active input of the NAD T 777 that will be
sent out to the corresponding rear panel ZONE 2 output port.
3 MUTE: Temporarily switch OFF or restore the Zone Volume level.
4 VOLUME [ d/f ]: Increase or decrease the loudness level of selected
Zone source. This is possible only if the VOLUME setting of ZONE 2
CONTROLS is set to VARIABLE.
5 PRESET [ a/s ]: Step up or down between stored radio presets. This
control button is possible if the selected Zone is “TUNER” and the active
tuner section has stored presets. This control button is not applicable to
T 777.
6 The following CD Player Zone buttons can control a compatible CD
Player. The CD Player has to be powered ON and disc loaded.
SKIP [ 0 ]: Go to the beginning of a track/le or previous track/le.
SKIP [ 9 ]: Go to the next track/le.
[ 4 ]: Start playback.
NOTE
The ZR 7 remote control will only control Zone 2 applications. Zone3
and Zone 4 could be congured and managed at the appropriate
Zone OSD menu using the front panel navigations keys as well as the
corresponding keys on the HTR 8 remote control. The HTR 8’s ‘CUSTOM’
device is also defaulted to Zone 2 remote control codes.
OPERATION
USING THE HTR 8 REMOTE CONTROL
44
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

NAD T 777 Specifications

General

Receiver type	Surround
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (4 Ohm)	260 W
Dynamic power per channel (8 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
S-Video inputs quantity	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
AM band range	522 - 1.620 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LED
Product color	Black
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Package weight	24200 g

Weight and Dimensions

Depth	425 mm
Width	435 mm
Height	172 mm
Weight	20500 g
