NI Digital System Development Board User Manual | © National Instruments | 53
Programming in Multisim
This section demonstrates how to program the DSDB in Multisim and create a project that
performs the following:
• Routes BTN0 and BTN1 through an AND gate then connects the output of the AND gate
to LED0, turning on LED0 only when BTN0 and BTN1 are pressed simultaneously.
Prerequisites
Hardware
• Digital System Development Board
Software
• Multisim 14.0.1 or later
• LabVIEW 2015 FPGA Module Xilinx Tools Vivado 2014.4 or later
OR
• Vivado HL WebPACK
Installation Instructions
1. Install Multisim 14.0.1 or later.
2. Install LabVIEW 2015 FPGA Module Xilinx Tools Vivado 2014.4 or later.
3. Install the Digilent drivers.
a. Navigate to
C:\NIFPGA\Programs and select the latest version of Vivado installed.
b. Continue to navigate through to
…\data\xicom\cable_drivers\nt64\digilent.
c. Run install_digilent.exe.
