NEC MultiSync P403 User Manual

English-32
You can control multiple monitors by using RS-232C, REMOTE IN or LAN daisy-chain connection.
NOTE: Multiple monitors that are daisy-chained have a limit to the connectable monitors.
When manually specify the ID number or control by the specifi ed ID number, please execute AUTO ID (see page 24)
previously.
Main Monitor Sub Monitors
Connector Connector
IN OUT IN OUT
RS-232C
LAN2 LAN1 LAN2REMOTE IN
LAN1
Connection
LAN1
LAN Cable
MultiSync MultiSync
LAN2 LAN1 LAN2
MultiSync
LAN Cable
Multiple Monitors Connection

NEC MultiSync P403 Specifications

General

Panel life	- h
Panel type	SPVA
Pixel pitch	- mm
Response time	8 ms
Display diagonal	40 \
Display brightness	700 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Contrast ratio (typical)	4000:1
Display number of colors	-
Display diagonal (metric)	101.6 cm
Active display area (W x H)	885.6 x 498.15 mm
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Ethernet LAN (RJ-45) ports	2
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	15.5 mm
Panel mounting interface	300 x 300 mm
Compatible products	C-tick; CE; FCC Class B; PSB; TÜV GS; UL/C-UL or CSA; VCCI
Operating hours (hours/days)	24/7
Sustainability certificates	RoHS
RMS rated power	20 W
Power consumption (standby)	1 W
Power consumption (typical)	135 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DVI
Certification	C-tick; CE; FCC;' PSB; RoHS; TÜV GS; UL/C-UL CSA; VCCI

Weight and Dimensions

Depth	66.5 mm
Width	920.6 mm
Height	532.2 mm
Weight	17000 g
